Camera
Image Sensor: | 1/2.8″ Progressive Scan CMOS
Effective Pixels: | 1920(H)x1080(V)
Signal System: | PAL/NTSC
Minimum Illumination: | F1.6, AGC On: Color: 0.05 lux, B/W : 0.01 lux, 0 lux with IR
White Balance: | Auto/Manual/ATW/Indoor/Outdoor/Daylight lamp/Sodium lamp
AGC: | Auto/Manual
BLC: | ON/OFF
HLC: | Support
WDR:| Support
Shutter Time: | 1-1/10,000s
Day& Night: | ICR
Digital Zoom: | 16X
Privacy Masking: | 8 privacy masks programmable
Auto Focus: | Auto / Semi-automatic / Manual
Lens
Focal Length: | 4.7-94.0mm, 20x
Zoom Speed: | Approx.3s(Optical Wide~Tele)
Angle of View: | 58.3-3.2 degree (Wide~Tele)
Minimum Working Distance: | 10~1,000mm(Wide~Tele)
Aperture Range: | F1.6~F3.5
Pan & Tilt
Pan Range: | 360°endless
Pan Speed: | Pan Manual Speed: 0.1°~80°/s, Pan Preset Speed: 80°/s
Tilt Range: | -15°-90° (Auto Flip )
Tilt Speed: | Tilt Manual Speed: 0.1°~80°/s, Tilt Preset Speed: 80°/s
Proportional Zoom:| Rotation speed can be adjusted automatically according to zoom multiples
Number of Preset: | 300
Patrol:| 8 patrols, up to 32 presets per patrol
Power loss recovery: | Support
Park Action: | Preset / Patrol / Pattern / Pan scan / Tilt scan / Random scan / Frame scan / Panorama scan
PTZ Position Display: | ON/OFF
Infrared
IR irradiation distance: | 100m
IR irradiation angle: | Adjustable by zoom
Network
Ethernet: | 10Base -T, /100Base-TX, RJ45 Connector
Max.Image Resolution: | 1920×1080
Frame Rate: | 50Hz:25fps(1920×1080), 25fps (1280×720),
60Hz:30fps(1920×1080), 30fps (1280×720)
Main Stream: | 50Hz:25fps (1920×1080,1280×960,1280×720), 50fps (1280×960,1280×720) ;
60Hz:30fps(1920×1080,1280×960,1280×720), 60fps (1280×960,1280×720)
Sub Stream:| 50Hz:25fps(704×576), 25fps(640×576), 25fps(320×288)
60Hz:30fps(704×480), 30fps(640×480), 30fps(320×240)
Third Stream: | 50Hz: 25fps(1920×1080, 1280×960, 1280×720, 704×576, 640×480,352×288)
60Hz: 30fps(1920×1080, 1280×960, 1280×720, 704×576, 640×480,352×288)
Image Compression: | H.264 / MJPEG
ROI encoding: | Support 4 areas with adjustable levels
Protocols: | IPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, ICMP, DHCP, PPPoE
No. of Simultaneous Users: | Up to 20 users
Dual Stream: | Support
Mini SD Card: | Support up to 128GB Micro SD/SDHC/SDXC card. Support Edge recording
User/Host Level: | Up to 32 users,3 Levels: Administrator, Operator and User
Security Measures:| User authentication (ID and PW),
Host authentication (MAC address)
IP address filtering
EZVIZ: | Support
Client GUI
Camera Control: | Pan/Tilt, Zoom, Focus, Click centering, Zoom by mouse dragging, Iris, preset calling and programming, auto mode
Date & Time Display: | Time: Week: Date, 6 formats on the Client
Client: | Support iVMS-4200
Web Browser: | IE 7+, Chrome 18 +, Firefox 5.0 +, Safari 5.02 +
General
Menu Language: | English
Power Supply: | 12 VDC &POE (802.3at,class4)
Power Consumption: | Max.20W
Working Temperature/Humidity: | -30°C ~ 65°C (-22°F ~ 149°F)
Protection Level: | IP66 standard (outdoor dome)
TVS 4,000V lightning protection, surge protection and voltage transient protection
Mounting: | Various mounting modes optional
Dimensions:| Φ164.5(mm)×295(mm)
Weight (approx.): | 2kg (4.41lbs)
